Touring
The T4.26 is a Touring Amplifiers.
- 4x1400W RMS / 8Ω (EIA standard)
- Studio grade preamp with PureSound topology
- Oversized Push-Pull Switch Mode Power Supply
- Load dependant Dynamic Voltage and Current limiters
- 4x2600W RMS / 4Ω (EIA standard)
- Class D output stage with High-Speed High Current MOSFETs
- SuperCharged 105°C long life capacitors
- Compact & Lightweight 2U 13kg Touring grade format
T-TOURING amplifiers are revolutionising the industry, with a host of inventive solutions, unique to this product range. New features include the proprietary PULSAR switch mode power supply and TrueSound, high-current, high-resolution class D output stage.
View
View
View
View
View
View
View
Technical specifications
| Power supply | Oversized switch mode with Push-Pull topology |
| Output stage | High-Speed High-Current 4th generation Class D |
| RMS Output Power | 4 x 2600W / 4Ω |
| 1kHz, 1% THD, EIA standard | 4 x 1400W / 8Ω |
| Maximum output voltage swing | 160V |
| Frequency response | 5~20,000Hz (-1dB) |
| Typical THD (half power, 1kHz, 8 ohms) | <0.05% |
| Signal to noise ratio | >110dB(A) |
| Crosstalk (1kHz) | >75dB |
| Input Impedance | 20 kΩ (Balanced) |
| Amplifier slew rate | >60V/us |
| Amplifier damping factor (8 ohms, 500Hz) | >800 |
| Nominal Voltage gain / Nominal Sensitivy | x50 (34dB) / 2.04V (+8.4dBu) under 8 ohms |
| Maximum input | +22dBu |
| Protections | Short-circuit, Over and Under-voltage, Over-current, Over-load, Temperature |
| Cooling | Temperature regulated 3pcs long life SUNON® MagLev fans |
| Input connectors | 4 balanced NEUTRIK® XLR IN + 4 XLR LINK |
| Output connectors | 4 NEUTRIK® SPEAKON NL4MP |
| Operating Voltage | 190~250V AC |
| Size (WxHxD) | 483x88x468mm |
| Weight | 13kg net, 15kg gross |
