S SD10000
10 kW Stereo. Pure Domination.
Description
Stereo flagship monster—the CELTO Acoustique SD10000 commands 2 × 2800 W @ 8 Ω (5000 W @ 4 Ω) for ultimate system headroom. Built for the largest line arrays and sub arrays in touring and installation. Extended chassis (326 mm) and 8 kg weight reflect massive internal reserves. Same premium preamp, protection, and Neutrik connectivity as series. When nothing less than maximum stereo power will do. The SD10000 turns amplification into domination.
Key Features
- 2 × 2800 W @ 8 Ω (5000 W @ 4 Ω) – flagship stereo authority
- 4th-gen high-current Class D for relentless headroom
- Studio-grade circuit with MUSE® capacitors and low distortion
- Extended chassis (8 kg) for extreme power handling
- Full protections and Neutrik I/O for demanding tours
Applications
Installation
Sound Architecture
Portable
Professional sound, on demand
Touring
Engineered to endure
Technical specifications
| Channels | 2 |
| RMS Power @ 8 Ω (per ch., EIA 1 kHz 1% THD) | 2800 W |
| RMS Power @ 4 Ω (per ch.) | 5000 W |
| RMS Power @ 2 Ω (per ch.) | 5300 W |
| Bridge @ 8 Ω | — |
| Bridge @ 4 Ω | — |
| Frequency Response (-1 dB) | 5 – 20 000 Hz |
| Typical THD | < 0.03 % / < 0.09 % |
| Signal to Noise Ratio (A-weighted) | > 107 dB |
| Crosstalk (1 kHz) | > 75 dB |
| Slew Rate | > 60 V/µs |
| Damping Factor (8 Ω) | > 800 |
| Voltage Gain | 34 dB |
| Input Impedance | 20 kΩ balanced |
| Preamp | Ultra-low distortion opamps + MUSE® Fine Gold capacitors |
| Output Stage / Class | 4th gen discrete Class D |
| Power Supply | LLC Resonant PULSAR SMPS + PFC |
| Cooling | Temperature-regulated brushless fans |
| Power Connector | PowerCon (locking) |
| Input Connectors | 4 × Neutrik balanced XLR |
| Output Connectors | 4 × Neutrik SpeakON NL4MP |
| Dimensions (W×H×D) mm | 482×45×326 (1U) |
| Weight Net | 8 kg |
