iFIX 8 G2

Small Cabinet. Big Attitude.

Description

Big sound in a small package—that's the promise of the CELTO iFIX8 G2, delivering a solid 300W RMS with exceptional efficiency. This coaxial installation loudspeaker is engineered for high-impact near-field reinforcement when paired with a subwoofer. Ideal for vibrant nightclubs, pubs, restaurants, multifunctional venues, auditoriums, and premium background music setups. Its 8" coaxial driver with HSP annular ring radiator HF delivers outstanding clarity and an impressive SPL-to-size ratio. Audiophile-grade crossover with Right-Phase design ensures seamless integration and precise imaging. Built from robust birch plywood and finished in black, white, natural wood, or custom colors to suit any interior. Multi-function yoke bracket included for quick, reliable wall or ceiling mounting. With 95 dB sensitivity and 124 dB peak SPL, it transforms compact spaces into sonic powerhouses. Proof that you don't need massive cabinets to achieve massive sound—the iFIX8 G2 simply gets the job done with style.

Key Features

  • Real 300W RMS with high-end sound quality
  • High Efficiency for incredible SPL to Size ratio
  • Coaxial transducer for unmatched spacial coherence
  • Next generation HSP Annular Ring Radiator HF
  • Audiophile grade crossover with Right-Phase topology
  • Birch plywood cabinet with smooth texture or varnish finish

Applications

Installation Sound Architecture

Technical specifications

Speaker type FIX Install Coaxial Satellite Speaker (must be used with Subwoofer)
Power Handling (AES standard) 300 W RMS / 1200 W Peak
Nominal impedance 8 ohms
Average sensitivity 95 dB / 1 W / 1 m
Maximum SPL (calculated) 120 dB RMS / 126 dB Peak
Frequency response (-6 dB no preset) 95~22000 Hz
Nominal directivity (-6 dB) 80° conical
Cabinet Exterior grade Birch plywood
Tongue & Groove construction
Cabinet finish Textured Waterborne Black coating
Acoustic PU foam behind Front grill
Floor monitor use No
Flying hardware Multi-function Yoke with dented ring
(can be mounted with screws or Eyebolt, Included in carton)
Mounting hardware Yes
for Yoke, wall mount bracket and CCA-MA
LF 8" coaxial CELTO ACOUSTIQUE
8CXT250
Woofer Chassis Die Cast Aluminium
Woofer Voice coil diameter 2.5" / 65 mm
HF CELTO ACOUSTIQUE
ACDX 40 (single magnet coaxial mounting)
HF RMS power (AES standard) 60 W above 1.5 kHz
HF Exit 1" / 25 mm
HF Voice coil diameter 1.7" / 44 mm
HF Diaphragm HSP Annular (High Strenght Polymer)
Crossover 1.6 kHz 2-way passive network
Connectivity PHOENIX MSTBV 2.5/4-GF-5.08
4pin header 2.5 mm² wire / 5.08 mm pitch
Speaker size (HxWxD) 243 x 250 x 250 mm
Speaker Weight 7 kg
Shipping information 9 kg
350 x 320 x 370 mm
Accessories WMBRKT20 (wall mount bracket)
Rust-Free Aluminum grill
