Description
Deep, visceral bass without the excess baggage—the CELTO CSW118 unleashes a commanding 1500W RMS (6000W peak) with clean, articulate low-end that reaches down to an impressive 34 Hz. This high-performance vented subwoofer is engineered for serious bass reinforcement in main PA systems, whether touring rigs or permanent installations on small to large stages, indoors or out. Ideal for stadiums, arenas, multifunctional venues, theatres, nightclubs, bars, and high-end karaoke rooms where powerful yet musical sub-bass is essential. At its core, a premium custom 18" CELTO driver with ferrite magnet and long-throw 4" in/out voice coil delivers exceptional excursion and control. Heavy-braced birch plywood cabinet with tongue-and-groove assembly ensures vibration-free performance even at maximum output. 97 dB sensitivity and a calculated 135 dB peak SPL provide room-shaking impact with minimal amplification strain. Dual 20 mm threaded top hats and genuine Neutrik SpeakON connectors make stacking, pole-mounting, and integration quick and reliable. Touring-grade textured waterborne black finish and robust CNC construction guarantee durability in the toughest environments. The CSW118 proves that earth-moving low end can be both devastatingly powerful and surprisingly refined—no tantrums required.
Key Features
- 1500W RMS power capacity
- Clean and deep reproduction
- Premium custom CELTO high excursion drivers
- Heavy braced, vibration free birch plywood cabinet
- Touring grade gloss-free black painting
Applications
Portable
Professional sound, on demand
Technical specifications
| Speaker type | Multi-purpose vented Subwoofer |
| Power Handling (AES standard) | 1500 W RMS / 6000 W Peak |
| Nominal impedance | 8 ohms |
| Average sensitivity | 97 dB / 1 W / 1 m |
| Maximum SPL (calculated) | 129 dB RMS / 135 dB Peak |
| Frequency response (-6 dB no preset) | 34~1500 Hz |
| Nominal directivity (-6 dB) | Omni in usable range |
| Cabinet |
Exterior grade Birch Plywood Heavily braced with Tongue & Groove |
| Cabinet finish |
Textured Waterborne Black coating Acoustic PU foam behind Front grill |
| Floor monitor use | N/A |
| Flying hardware | No |
| Mounting hardware | 2pcs M20 thread socket |
| LF |
18" CELTO ACOUSTIQUE 18SW1500-8 |
| Woofer Chassis | Die Cast Aluminium |
| Woofer Voice coil diameter | 4" / 100 mm long throw |
| Crossover | No, active mode only |
| Connectivity |
Genuine NEUTRIK 2pcs Speakon NL4 mP |
| Speaker size (HxWxD) | 632 x 570 x 650 mm |
| Speaker Weight | 44 kg |
| Shipping information |
51 kg 735 x 675 x 750 mm |
| Accessories |
CSW118-SBAG (padded cover bag) CPC-70 (pole bar with crank) SUBWHKIT100C (castor wheel kit) |
Product files
| Name | Category | Type | Size | |
|---|---|---|---|---|
|
CELTO_CPC-70_A0_20250721_WEB_CAD
CELTO_CPC-70_A0_20250721_WEB_CAD
|
CELTO_CPC-70_A0_20250721_WEB_CAD | 33.1 KiB | Download | |
|
CELTO_SUBWHKIT100C_A0_20250721_WEB_CAD
CELTO_SUBWHKIT100C_A0_20250721_WEB_CAD
|
CELTO_SUBWHKIT100C_A0_20250721_WEB_CAD | 37.1 KiB | Download | |
|
CELTO_CSW118_A0_20250717_WEB_CAD
CELTO_CSW118_A0_20250717_WEB_CAD
|
CELTO_CSW118_A0_20250717_WEB_CAD | 72.0 KiB | Download | |
|
CELTO_SUBWHKIT100C_A0_20250721_WEB_CAD
CELTO_SUBWHKIT100C_A0_20250721_WEB_CAD
|
CELTO_SUBWHKIT100C_A0_20250721_WEB_CAD | DWG | 740.1 KiB | Download |
|
CELTO_CPC-70_A0_20250721_WEB_CAD
CELTO_CPC-70_A0_20250721_WEB_CAD
|
CELTO_CPC-70_A0_20250721_WEB_CAD | DWG | 781.7 KiB | Download |
|
CELTO_CSW118_A0_20250717_WEB_CAD
CELTO_CSW118_A0_20250717_WEB_CAD
|
CELTO_CSW118_A0_20250717_WEB_CAD | DWG | 842.0 KiB | Download |
